H-SERIES AMPLIFIER

NEU!!!

• HELON-SERIES 1-Channel
• digital MONO high-power-amplifier and SMD technology
• QUADMOSFET power supply
• CLIP/VOLT/TEMPERATURE DISPLAY and LIMITER
• Low Pass Filter(24dB)
• Subsonicfilter(24dB)
• BASS BOOST +9 dB at 45 Hz
• variable adjustable 0-180° Phaseshift
• up to 90% efficiency
• including RTC-PLUS

• 1x 1650 WRMS 4 Ohm Mono
• 1x 3100 WRMS 2 Ohm Mono
• 1x 5000 WRMS 1 Ohm Mono

ATTENTION: no guarantee LINK MODUS

• 1x 10000 WRMS an 2 Ohm (2x amps linked at 14V)

• 550 x 63 x 256 mm

• H-5000.1 D Remote Control
• The RTC-PLUS regulates:
  – the limiter
  – shows the temperature of the power amp
  – what voltage is present
  – when the power amp starts clipping
• size: 78x66x27,5 mm
• cable length 4,5m
